AT24C16C-SSHM-T

AT24C16C-SSHM-T, Two-wire Automotive Serial EEPROM, 7.0V, 5.0 mA, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.20 / Piece
1000 ~ 10000 :	0.15 / Piece
10000 ~ 100000 :	0.10 / Piece

PartNumber:: AT24C16C-SSHM-T

Brand:: ATMEL Corporation - ATMEL | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-31

From Other Seller

Part Number:AT24C16C-SSHM-T
US $0.10 - 0.20
Quantity:

piece

Product Summary

The AT24C16C-SSHM-T is a Two-wire Automotive Serial EEPROM. The AT24C16C-SSHM-T is optimized for use in many automotive applications where low-power and low-voltage operation are essential. The device is available in space-saving 8-lead PDIP and 8-lead JEDEC SOIC packages. It is accessed via a two-wire serial interface.

Parametrics

AT24C16C-SSHM-T absolute maximum ratings: (1)Operating Temperature:-55℃ to +125℃; (2)Storage Temperature:-65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground:-1.0V to +7.0V; (4)Maximum Operating Voltage:6.25V; (5)DC Output Current:5.0 mA.

Features

AT24C16C-SSHM-T features: (1)Two-wire Serial Interface; (2)Schmitt Trigger, Filtered Inputs for Noise Suppression; (3)Bi-directional Data Transfer Protocol; (4)100 kHz (2.7V) and 400 kHz (5V) Compatibility; (5)Write Protect Pin for Hardware Data Protection; (6)8-byte Page (1K, 2K), 16-byte Page (4K, 8K, 16K) Write Modes; (7)Partial Page Writes are Allowed; (8)Self-timed Write Cycle (5 ms max); (9)High-reliability:Endurance: 1 Million Write Cycles,Data Retention: 100 Years; (10)8-lead PDIP and 8-lead JEDEC SOIC Packages; (11)Medium-voltage and Standard-voltage Operation:5.0 (VCC = 4.5V to 5.5V),2.7 (VCC = 2.7V to 5.5V); (12)Internally Organized 128 x 8 (1K), 256 x 8 (2K), 512 x 8 (4K),1024 x 8 (8K) or 2048 x 8 (16K).
