AD822AN

AD822AN, FET input op amp, 36 V, 10 kHz, 800 μA, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.20~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.00 / Piece
101 ~ 1000 :	1.50 / Piece
1001 ~ 10000 :	1.20 / Piece

PartNumber:: AD822AN

Brand:: Analog Devices Inc - ADI | Pack: DIP | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-03

From Other Seller

Part Number:AD822AN
US $1.20 - 2.00
Quantity:

piece

Product Summary

The AD822AN is a dual precision, low power FET input op amp that can operate from a single supply of 3.0 V to 36 V or dual supplies of ±1.5 V to ±18 V. It has true single-supply capability with an input voltage range extending below the negative rail, allowing the AD822AN to accommodate input signals below ground in the single-supply mode. The applications of the AD822AN are Battery-powered precision instrumentation, Photodiode preamps, Active filters, 12-bit to 14-bit data acquisition systems, Medical instrumentation, Low power references and regulators.

Parametrics

AD822AN absolute maximum ratings: (1)Supply Voltage :±18 V ; (2)Internal Power Dissipation:Observe derating curves ; (3)Input Voltage:(+VS + 0.2 V) to -(20 V + VS) ; (4)Output Short Circuit Duration:Indefinite ; (5)Differential Input Voltage:±30 V ; (6)Storage Temperature Range:–65℃ to +125℃; (7)Operating Temperature Range: AD822 A Grade and B Grade:–40℃ to +85℃; (8)Lead Temperature Range (Soldering, 60 sec):260℃.

Features

AD822AN features: (1)True single-supply operation ; (2)Output swings rail-to-rail ; (3)Input voltage range extends below ground ; (4)Single-supply capability from 3 V to 36 V ; (5)Dual-supply capability from ±1.5 V to ±18 V ; (6)High load drive ; (7)Capacitive load drive of 350 pF, G = +1 ; (8)Minimum output current of 15 mA ; (9)Excellent ac performance for low power: 800 μA maximum quiescent current per amplifier, Unity gain bandwidth: 1.8MHz, Slew rate of 3.0 V/μs ; (10)Good dc performance ; (11)800 μV maximum input offset voltage ; (12)2 μV/℃ typical offset voltage drift ; (13)25 pA maximum input bias current ; (14)Low noise: 13 nV/√Hz @ 10 kHz, No phase inversion.
