AD8073JRZ

SOIC, 500 MHz, G = +-1 and +2 Triple Video Buffers, AD8073JRZ, 12.0V, 1W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: AD8073JRZ

Brand:: Analog Devices - ADI | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-31

From Other Seller

Part Number:AD8073JRZ
US $0.30 - 0.50
Quantity:

piece

Product Summary

The AD8073JRZ is a high-speed triple video buffer with G = +1 and +2 respectively. The device has a –3 dB full signal bandwidth in excess of 450 MHz, along with slew rates in excess of 1400 V/μs, with better than –80 dB of all hostile crosstalk and 90 dB isolation. The AD8073JRZ is useful in many high-speed applications. The differential gain and differential phase error are 0.01% and 0.01°. Gain flatness of 0.1 dB up to 50 MHz makes the AD8073JRZ ideal for RGB buffering or driving. The AD8073JRZ consumes less than 30 mA on a ± 5 V supply. The applications of the AD8073JRZ include: RGB Buffer in LCD and Plasma Displays, RGB Driver, Video Routers.

Parametrics

AD8073JRZ absolute maximum ratings: (1)Supply Voltage :12.0V; (2)Internal Power Dissipation2, 3 AD8074/AD8075 16-Lead TSSOP (RU):1 W; (3)Input Voltage; (4)IN0, IN1, IN2: VEE≤VIN≤VCC; (5)OE: DGND≤VIN≤VCC; (6)Output Short Circuit Duration: Indefinite3; (7)Storage Temperature Range: –65℃ to +150℃; (8)Lead Temperature Range (Soldering 10 sec):300℃.

Features

AD8073JRZ features: (1)Dual Supply ±5 V; (2)High-Speed Fully Buffered Inputs and Outputs; (3)600 MHz Bandwidth (–3 dB) 200 mV p-p; (4)500 MHz Bandwidth (–3 dB) 2 V p-p; (5)1600 V/μs Slew Rate, G = +1; (6)1350 V/μs Slew Rate, G = +2; (7)Fast Settling Time: 4 ns; (8)Low Supply Current: ＜30 mA; (9)Excellent Video Specifications (RL = 150Ω): Gain Flatness of 0.1 dB to 50 MHz, 0.01% Differential Gain Error, 0.01° Differential Phase Error; (10)All Hostile Crosstalk; (11)–80 dB @ 10 MHz; (12)–50 dB @ 100 MHz; (13)High OFF Isolation of 90 dB @ 10 MHz; (14) Low Cost; (15) Fast Output Disable Feature.
