Product Summary

The AD712JRZ-REEL7 is a dual precision, low cost, high speed BiFET op amp. The AD712JRZ-REEL7 is a high speed, precision, monolithic operational amplifier offering high performance at very modest prices. Its very low offset voltage and offset voltage drift are the results of advanced laser wafer trimming technology. These performance benefits allow the user to easily upgrade existing designs that use older precision BiFETs and, in many cases, bipolar op amps. The superior ac and dc performance of this op amp makes it suitable for active filter applications. With a slew rate of 16 V/μs and a settling time of 1 μs to ±0.01%, the AD712JRZ-REEL7 is ideal as a buffer for 12-bit digital-to-analog and analog-to-digital converters and as a high speed integrator. The settling time is unmatched by any similar IC amplifier. The combination of excellent noise performance and low input current also make the AD712JRZ-REEL7 useful for photo diode preamps. Common-mode rejection of 88 dB and open-loop gain of 400 V/mV ensure 12-bit performance even in high speed unity-gain buffer circuits.

Parametrics

AD712JRZ-REEL7 absolute maximum ratings: (1)Supply Voltage: ±18 V; (2)Input Voltage: ±18 V; (3)Storage Temperature Range: -65℃ to +150℃; (4)N-Suffix and R-Suffix: -65℃ to +125℃; (5)Operating Temperature Range: 0℃ to 70℃; (6)Lead Temperature Range (Soldering 60 sec): 300℃.

Features

AD712JRZ-REEL7 features: (1)Enhanced replacement for LF412 and TL082; (2)AC performance Settles to ±0.01% in 1.0 μs; (3)16 V/μs minimum slew rate ; (4)3 MHz minimum unity-gain bandwidth ; (5)MIL-STD-883B parts available; (6)Single version available: AD711; (7)Quad version: AD713.
