AD637AQ

monolithic rms-to-dc converter, SOP16, 500 V, 108 mW, 600 kHz, 2.2mA to 350 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $30.00~50.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	50.00 / Piece
11 ~ 100 :	40.00 / Piece
101 ~ 1000 :	30.00 / Piece

PartNumber:: AD637AQ

Brand:: Analog Devices - ADI | Pack: DIP | D/C: 13+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-31

From Other Seller

Part Number:AD637AQ
US $30.00 - 50.00
Quantity:

piece

Product Summary

The AD637AQ is a complete high accuracy monolithic rms-to-dc converter that computes the true rms value of any complex waveform. The AD637AQ offers performance that is unprecedented in inte-grated circuit rms-to-dc converters and comparable to discrete and modular techniques in accuracy, bandwidth and dynamic range. A crest factor compensation scheme in the AD637AQ per-mits measurements of signals with crest factors of up to 10 with less than 1% additional error. The circuit wide bandwidth per-mits the measurement of signals up to 600 kHz with inputs of 200 mV rms and up to 8 MHz when the input levels are above 1 V rms.

Parametrics

AD637AQ absolute maximum ratings: (1)ESD Rating: 500 V; (2)Supply Voltage: ±18 V dc; (3)Internal Quiescent Power Dissipation: 108 mW; (4)Output Short-Circuit Duration: Indefinite; (5)Storage Temperature Range: –65 to +150℃; (6)Lead Temperature Range (Soldering 10 secs): +300℃; (7)Rated Operating Temperature Range: 0 to +70℃.

Features

AD637AQ features: (1)High Accuracy: 0.02% Max Nonlinearity, 0 V to 2 V RMS Input; 0.10% Additional Error to Crest Factor of 3; (2)Wide Bandwidth: 8MHz at 2 V RMS Input; 600 kHz at 100 mV RMS; (3)Computes: True RMS; Square; Mean Square; Absolute Value; (4)dB Output (60 dB Range); (5)Chip Select-Power Down Feature Allows: Analog 3-State Operation; Quiescent Current Reduction from 2.2mA to 350 mA; (6)Side-Brazed DIP, Low Cost Cerdip and SOIC.
