74LV164PW,118

74LV164PW,118, 8-bit serial-in/parallel-out shift register, 750 mW, 5.5V, 50 mA, TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1000 ~ 10000 :	0.40 / Piece
10000 ~ 100000 :	0.30 / Piece

PartNumber:: 74LV164PW,118

Brand:: NXP Semiconductors - nxp | Pack: TSSOP | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-14

From Other Seller

Part Number:74LV164PW,118
US $0.30 - 0.50
Quantity:

piece

Product Summary

The 74LV164PW,118 is an 8-bit serial-in/parallel-out shift register. A LOW on the master reset (MR) input override all other input and clears the register asynchronously, forcing all output LOW.

Parametrics

74LV164PW,118 absolute maximum ratings: (1)VCC DC supply voltage: –0.5 to +7.0 V; (2)±I IK DC input diode current VI < –0.5 or VI > VCC + 0.5V: 20 mA; (3)±IOK DC output diode current VO < –0.5 or VO > VCC + 0.5V: 50 mA; (4)±IO DC output source or sink current – standard outputs –0.5V < VO < VCC + 0.5V: 25 mA; (5)±IGND, ±ICC DC VCC or GND current for types with –standard outputs: 50 mA; (6)Tstg Storage temperature range: –65°C to +150 °C; (7)PTOT Power dissipation per package –plastic DIL for temperature range: –40 to +125°C: 750 mW.

Features

74LV164PW,118 features: (1)Wide operating voltage: 1.0 to 5.5V; (2)Optimized for Low Voltage applications: 1.0 to 3.6V; (3)Accepts TTL input levels between VCC = 2.7V and VCC = 3.6V; (4)Typical VOLP (output ground bounce)< 0.8V @ VCC = 3.3V, Tamb = 25°C; (5)Typical VOHV (output VOH undershoot)< 2V @ VCC = 3.3V, Tamb = 25°C; (6)Gated serial data inputs; (7)Asynchronous master reset; (8)Output capability: standard; (9)ICC category: MSI.
