The 74HCT14D is a high-speed Si-gate CMOS device and is pin compatible with low power Schottky TTL (LSTTL) . The 74HCT14D is specified in compliance with JEDEC standard no. 7A. The 74HCT14D provides six inverting buffers with Schmitt-trigger action. Applications of the 74HCT14D include:Wave and pulse shapers, Astable multivibrators and Monostable multivibrators.
Parametrics
74HCT14D absolut maximum ratings: (1) supply voltage Vcc: 4.5 to 5.5V; (2) input voltage VI: 0 to Vcc; (3) output voltage Vo: 0 to Vcc; (4) operating ambient temperature Tamb: -40 to +85°C.
Features
74HCT14D features: (1) (1) Complies with JEDEC standard no. 7A; (2) ESD protection: HBM EIA/JESD22-A114-A exceeds 2000V, MM EIA/JESD22-A115-A exceeds 200V; (3) Specified from -40 to +85°C and -40 to +125 °C.
Diagrams
