Product Summary

  • CRIMP SOCKET, 26-30AWG
  • Series: Minitek
  • For Use With: 2mm Minitek System
  • Contact Gender: Socket
  • Contact Material: Phosphor Bronze
  • Contact Plating: Gold
  • Contact Termination: Crimp
  • Wire Size AWG Min: 26AWG
  • Wire Size AWG Max: 30AWG
  • SVHC: No SVHC (20-Jun-2013)
  • Approval Bodies: CSA, UL
  • Cable Diameter Max: 0.457mm
  • Cable Diameter Min: 0.254mm
  • Connector Type: Wire to Board
  • Contact Resistance: 20mohm
  • Contact Size: 26
  • Current Rating: 2A
  • Gender: Receptacle
  • Insulation Resistance: 1000Mohm
  • Material: Phosphor Bronze
  • No. of Mating Cycles: 100
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -40°C
  • Termination Method: Crimp
  • Voltage Rating V AC: 200V
  • Voltage Rating V DC: 200V
  • Wire Area Size Max: 0.078mm2
  • Wire Area Size Min: 0.516mm2
  • Wire Size: 26AWG
  • Withstand Voltage: 650V

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
77138-001LF
77138-001LF
FCI
Headers & Wire Housings MNTK CTW 8uAU RECPT
Data Sheet
0-1: $0.09
1-25: $0.06
25-100: $0.05
100-250: $0.05
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
7713
7713
Keystone Electronics
Circuit Board Hardware - PCB CERAMIC THRD .500
Data Sheet
0-1: $1.18
1-100: $1.07
100-500: $0.89
500-1000: $0.84
77138-001LF
77138-001LF
FCI
Headers & Wire Housings MNTK CTW 8uAU RECPT
Data Sheet
0-1: $0.09
1-25: $0.06
25-100: $0.05
100-250: $0.05
77139-001
77139-001
FCI
Headers & Wire Housings CTW CONT 32-36 AWG
Data Sheet
Negotiable
77139-101LF
77139-101LF
FCI
Headers & Wire Housings CTW CONTACT 32-36 AWG
Data Sheet
Negotiable
77139-101
77139-101
FCI
Headers & Wire Housings CTW CONTACT 32-36 AWG
Data Sheet
Negotiable
77138-101-X
77138-101-X
FCI
Headers & Wire Housings MINITEK TERM 30 GOLD
Data Sheet
Negotiable
