Product Summary

The PME261JC6100KR30 is a General purpose AC/DC converter. The applications of the PME261JC6100KR30 include For general use in DC and low frequency pulse applications.

Parametrics

PME261JC6100KR30 absolute maximum ratings: (1)Rated voltage UR, VAC: 500 V; (2)Rated voltage UR, VDC: 1000 V; (3)Capacitance range, μF: 15 0.001 - 0.1; (4)Capacitance tolerance: ± 20% code M; (5)Temperature range AC application: -40 to +70 ℃; (6)DC application: -40 to + 100 ℃; (7)Climatic category: IEC 40/070/56; (8)Dissipation factor: ≤ 1.3 % at 1 kHz; (9)Insulation resistance: C ≤ 0.33 μF 12000 MΩ.

Features

PME261JC6100KR30 features: (1)IEC Publ. 166 Type 1; (2)High dU/dt capability; (3)Excellent self-healing properties; (4)Good resistance to ionisation due to impregnated dielectric; (5)Approved according to SE-MIL-QPL; (6)The capacitors meet the most stringent IEC humidity class, 56 days; (7)The impregnated paper ensures excellent stability giving outstanding reliability properties, especially in applications having continuous operation.

Diagrams

PME261JC6100KR30 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PME261JC6100KR30
PME261JC6100KR30
Kemet
Film Capacitors 1000volts 0.10uF 10% LS 20.4mm
Data Sheet
0-1: $2.30
1-50: $2.00
50-100: $1.87
100-500: $1.73
