Product Summary
The C1608X7R1H104K080AA is an international rectifier. The C1608X7R1H104K080AA is fully integrated and highly efficient DC/DC voltage regulator. Applications are (1)Notebook and Desktop Computers; (2)Consumer Electronics – STB, LCD, TV, Printers; (3)12V and 24V Distributed Power Systems; (4)General Purpose POL DC-DC Converters; (5)Game Consoles and Graphics Card.
Parametrics
C1608X7R1H104K080AA absolute maximum ratings: (1)VIN, FF: -0.3V to 30V; (2)VCC, PGOOD, EN: -0.3V to 8V; (3)BOOT: -0.3V to 38V; (4)PHASE: -0.3V to 30V (DC), -5V (100ns); (5)BOOT to PHASE: -0.3V to 8V; (6)ISET: -0.3V to 30V, 30mA; (7)PGND to GND: -0.3V to +0.3V; (8)All other pins: -0.3V to 3.9V; (9)Storage Temperature Range: -65°C to 150°C; (10)Junction Temperature Range: -40°C to 150°C; (11)ESD Classification: JEDEC Class 1C; (12)Moisture Sensitivity Level: JEDEC Level 2 @ 260°C (Note 2).
Features
C1608X7R1H104K080AA features: (1)Input Voltage Range: 3V to 27V; (2)Output Voltage Range: 0.5V to 12V; (3)Continuous 12A Load Capability; (4)Constant On-Time Control; (5)Compensation Loop not Required; (6)Excellent Efficiency at Very Low Output Currents; (7)Programmable Switching Frequency and Soft Start; (8)Thermally Compensated Over Current Protection; (9)Power Good Output; (10)Precision Voltage Reference (0.5V, +/-1%); (11)Enable Input with Voltage Monitoring Capability; (12)Pre-bias Start Up; (13)Thermal Shut Down; (14)Under/Over Voltage Fault Protection; (15)Forced Continuous Conduction Mode Option; (16)Small, Low Profile 5mm x 6mm QFN Package.
